3840 X 601 65.7Inch Stretched Bar Lcd JB657TP01 For Metro Application

Name: 3840 X 601 65.7Inch Stretched Bar Lcd JB657TP01 For Metro Application
Brand: 3840 X 601 65.7Inch Stretched Bar Lcd JB657TP01 For Metro Application
SKU: JB657TP01
Rating: 4.8 (102 reviews)

Product Details

Place of Origin: China

Model Number: JB657TP01

Payment & Shipping Terms

Minimum Order Quantity: 1

Price: negotiable

Packaging Details: factory original packing

Delivery Time: 3-5 working days

Payment Terms: T/T

Supply Ability: 5000pcs/month

Get Best Price

Product Details

Product Description

Highlight:
                                                                                                                                                                                                                                                3840 X 601 stretched bar lcd, 65.7Inch stretched bar monitor, Metro stretched lcd screen


Size:	65.7Inch	Resolution:	3840*601
Luminance:	750cd/m2	Interface Type:	V-By-One 51PINS
View Angle:	89/89/89/89	Working Temp.:	0 ~ 70 °C

Size:	65.7Inch
Resolution:	3840*601
Luminance:	750cd/m2
Interface Type:	V-By-One 51PINS
View Angle:	89/89/89/89
Working Temp.:	0 ~ 70 °C

3840 X 601 65.7Inch Stretched Bar Lcd JB657TP01 For Metro Application

65.7Inch Resolution 3840*601 Stretched Lcd Panel JB657TP01 for Metro Application

The JB657TP01 is a Color Active Matrix Liquid Crystal Display with an integral the Source PCB and Gate

implanted on Panel (GIP). The matrix employs a-Si Thin Film Transistor as the active element.

It is a transmissive type display operating in the normally black mode. It has a 69 inch diagonally measured active display area with QWUXGA resolution (601 vertical by 3840 horizontal pixel array).

Sub-pixels are constructed with Red, Green, Blue and White. Each pixel is divided into RGB or WRG or BWR

or GBW or dots which are arranged in vertical stripes. Gray scale or the luminance of the sub-pixel color is

determined with a 10-bit gray scale signal for each dot. Therefore, it can present a palette of more than

1.07Bilion colors. It has been designed to apply the 10-bit 8 Lane V by One interface.

It is intended to support LCD TV, PCTV where high brightness, super wide viewing angle, high color gamut,

high color depth and fast response time are important.
