Product Details
Place of Origin: China
Model Number: DV215FHM-NN0
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: negotiable
Packaging Details: factory original packing
Delivery Time: 3-5 working days
Payment Terms: T/T
Supply Ability: 5000pcs/month
Luminance: |
500 Cd/m² (Typ.) |
Resolution: |
1920(RGB)×1080, FHD 102PPI |
Contrast Ratio: |
1000:1 (Typ.) (TM) |
Response Time: |
14 (Typ.)(G To G) |
Applicatiion: |
Digital Signage And Industrial Monitor |
Luminance: |
500 Cd/m² (Typ.) |
Resolution: |
1920(RGB)×1080, FHD 102PPI |
Contrast Ratio: |
1000:1 (Typ.) (TM) |
Response Time: |
14 (Typ.)(G To G) |
Applicatiion: |
Digital Signage And Industrial Monitor |
21.5Inch FHD Lcd Panel DV215FHM-NN0 for Digital Signage and Industry monitor
DV215FHM-NN0 is a 21.5" diagonal a-Si TFT-LCD display panel product from BOE Technology Group Co., Ltd. (hereafter called BOE), with an integral WLED backlight system, without backlight driver, without touch screen. It features an operating temperature range of 0 ~ 50°C , a storage temperature range of -20 ~ 60°C
| Outline Dim. |
|---|
| Luminance |
| View Direction |
| Viewing Angle |
| Support Color |
| Weight |
| Frame Rate |
| 495.6(W)×292.2(H)×11.2(D) mm |
| 500 cd/m² (Typ.) |
| Symmetry |
| 89/89/89/89 (Typ.)(CR≥10) |
| 16.7M 73% NTSC |
| 1.97Kgs (Typ.) |
| 60Hz |
| Treatment |
| Contrast Ratio |
| Response Time |
| Operating Mode |
| Light Source |
| Designed For |
| Touch Panel |
| Antiglare, Hard coating (3H) |
| 1000:1 (Typ.) (TM) |
| 14 (Typ.)(G to G) |
| ADS, Normally Black, Transmissive |
| WLED [24S3P] , 30K hours , W/O Driver |
| Without |
| Interface Type | LVDS (2 ch, 8-bit) 30 pins Connector |
|---|---|
| Power Supply | 5.0V (Typ.) |
| Environment | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
